ALL THE SMOOTHNESS YOU NEED FOR 27,5+

The 27,5” Plus is winning more and more preference in the world of mountain biking. Today, this size offers the greatest possible comfort from the larger tires with greater air volume. Linea 4 wheels, with their 40 mm wide rim, represent the ideal choice for those who ride the 27,5” Plus.

The hookless aluminium rim guarantees the best adhesion for the tire. The next generation rear hub supplies the highest level of performance. The Wide Position Design (WPD) provides the best smoothness and stability. Bearing life is doubled by the exclusive Full Contact Technology (FCT). Ordinary maintenance is even simpler to carry out with the Easy Maintenance System (EMS).

Linea 4 wheels provide a concentration of technology dedicated to the new standard that is already very popular with riders. If you want the greatest comfort together with the highest level of performance, Linea 4 wheels for 27,5” Plus are the wheels designed for you.

Technologies
  • FCT Formula
  • Wide Position Design

Technical specifications

HUB

Style
EN / FR
Bearing Technology
Cartridge Technology
Color
Anodized Black
Freehub Body Shimano
4-Pawl / 60 Engagement Points
Freehub Body SRAM XD
4-Pawl / 60 Engagement Points

END CAPS

Compatibility Front
15x110
Compatibility Rear
12x148

RIM

Material
6082 T6 Alloy

DIMENSIONS

Interior / Exterior
40mm / 43mm
Height
20mm
Color
Black
Spokes
28 Straight Pull Double Butted Laced 2-Cross
Nipples
Self Locking Black Alloy

WEIGHT

Front
910g
Rear
1084g
Has it happened to you when attempting to perform regular maintenance on your hubs, you discover it is one of the most difficult parts of your bike to service? Whether in your personal workshop or your favorite local bike shop, the design of our hubs allows for quick service and maintenance. Thanks to Easy Maintenance System, ordinary maintenance is no longer a problem.
Full Contact Technology
With this special design, the bearings are more enclosed with better protected by the hub. All of the internal parts of the hub are in direct contact with the bearings. This design creates a protective structure with the added advantage of reducing the lateral movements of the bearings and eliminating the infiltration of water and dirt. FCT has been imagined not only to improve the performance of the hubs, but also to make the bearings last longer while reducing maintenance to a minimum.
Wide Position Design
Thanks to the distance between the hub bearings we have greatly increased hub performance and durability, compared with a traditional hub. The general stability of the axle, whose flex places the most stress on the bearings, is specifically increased due to the wider bearing platform.This more stable and sturdy bearing platform leads to a consistent reduction of axle flex, with a successive improvement in rotation. WPD also improves the durability of the bearings making a longer lasting and smoother spinning hub.
